RFID Plastic Seal

RFID Plastic Seal

Upon manual tampering, the embedded chip will be irreparably compromised.
It can be adaptively deployed across diverse scenarios and object geometries.
Minimal replacement requirements significantly reduce operational costs and maintenance overhead.
It enables seamless integration with the enterprise's existing management infrastructure.
Send Inquiry
Description

Our RFID plastic seal attaches through a closure or fixing point without an adhesive label. The 325 × 27 × 9 mm hanging-style design combines a PP housing with an M4E chip, allowing warehouse and inspection teams to connect a sealed item with its electronic record.

RFID Plastic Seal Specifications

This configuration uses a 920.5–924.5 MHz operating band and a reference free-air reading distance of up to 2 m. Confirm the reader settings and installed performance for the intended site.

Parameter Listed Configuration
Overall dimensions 325 × 27 × 9 mm
RFID chip M4E
TID / UID 96 bits
EPC memory Up to 496 bits; confirm the final memory allocation
User memory 128 bits listed; confirm availability with the required EPC length
Access password 32 bits
Kill password 32 bits
Operating frequency 920.5–924.5 MHz
Housing material PP, polypropylene
Reference read range Up to 200 cm in free air, depending on the reader
Installation Hanging / cable-tie style
Color Green; customized colors available

Fit the Seal to the Opening

The tie must pass through the attachment points and prevent access without disturbing the closure. Overall product length is not the usable loop circumference.

Paired Eyelets

For boxes and transport totes, pass the seal through lid and body eyelets. Check that the closed loop prevents the lid from lifting enough to remove contents.

Bag Closures

Evaluate the seal on the filled bag, not an empty sample. The neck or eyelets must retain the tie without allowing the bag to slip through the loop.

Equipment Access Points

Use suitable panel and frame fixing points. Keep the RFID head accessible to the reader and clear of moving components or sharp edges.

Use the RFID Identity in Warehouse Checks

An RFID plastic seal can reduce repeated manual data entry when its encoded identity is assigned to the correct item before dispatch.

Operation Seal Handling System Record
Packing Apply the seal and read its identifier. Associate the EPC with the box, bag or order.
Dispatch Read the prepared items within the defined reader zone. Compare captured identities with the dispatch list.
Receiving Scan the arriving seal and inspect the physical closure. Accept the expected identity or flag a discrepancy.
Opening Remove the seal using the approved procedure. Close the assignment before issuing a replacement.

Test Removal Behavior on Your Closure

Evaluate both physical damage and RFID response. The response can depend on where the seal is disturbed and how it is attached.

Intact Read

Record the EPC and available TID after installation. Use the same reader, distance and orientation for subsequent comparisons.

Controlled Removal

Use dedicated samples to test normal cutting and attempted removal at the actual fixing point. Record damage to the tie, head and closure.

Post-Removal Inspection

Repeat the RFID read and compare the physical condition. An unreadable tag alone does not identify the cause of failure.

Reader and Encoding Requirements

Reader Setup

  • Country of use and permitted operating band
  • Reader and antenna models
  • Handheld or fixed-point inspection
  • Expected distance and item orientation
  • Nearby metal, liquids and adjacent tags

Data Setup

  • Required EPC length and numbering format
  • User-memory content and capacity
  • TID capture requirements
  • Write-protection and password policy
  • Relationship between seal and item records

Sample Approval Before Bulk Supply

We can review your closure dimensions, color and RFID data requirements before confirming the order configuration.

Approval Item Sample Check Information to Record
Mechanical fit Apply the seal to the actual loaded package or equipment. Loop fit, locking engagement and access restriction.
RFID response Read at the intended inspection point. Reader settings, distance and successful read count.
Encoding Read back the programmed EPC and user data. Data match, memory allocation and write protection.
Removal behavior Disturb or remove a dedicated test sample. Physical evidence and resulting RFID response.
Handling conditions Assess the relevant storage and transport exposure. Housing condition, locking function and readability.

Related Seals and Readers

Choose the closure construction and electronic functions according to the application. Sensor seals and metal-compatible designs require their own model selection.

RFID Plastic Seal Questions

Is the housing made from PP or ABS? +

We specify PP housing for this 325 × 27 × 9 mm configuration. Include any required material grade or environmental conditions when requesting an order specification.

Will this model work with every UHF reader? +

The specified operating band is 920.5–924.5 MHz. Send us the country of use and reader model so we can check the required configuration rather than assume worldwide compatibility.

Can it be read from two meters after installation? +

Two meters is the reference free-air distance. Installed range depends on the reader, antenna, power setting, package contents and seal orientation. Test the completed installation before setting a required operating distance.

Can the seal store 496 bits of EPC and 128 bits of user data? +

Confirm the final memory map before encoding. The maximum EPC figure and listed user-memory capacity should not be assumed to be simultaneously available without checking the selected chip configuration.

Does an access password provide encrypted authentication? +

An access password is not the same as cryptographic authentication or encrypted communication. If the project requires stronger authentication, specify that requirement separately from ordinary identification and write protection.

Does cutting any part of the tie always disable the chip? +

That behavior must be established through sample testing. Cutting the tie, disturbing the locking head and damaging the RFID circuit may produce different results. Specify the required removal behavior before approval.

Can several seals be read during a warehouse check? +

Batch identification can be evaluated with a compatible UHF reader. Test the actual tag count, spacing, package contents and reader zone to determine whether the required items are captured without unwanted nearby reads.

What information is needed for a quotation? +

Please provide closure photographs and dimensions, country of use, reader model, required distance, EPC and user-data format, removal requirements, color, quantity and delivery destination.

Match the Plastic Seal to Your Closure

Send us your closure photos, reader setup, required RFID data and order quantity. We will review the fit, frequency and encoding requirements for your application.
