overview
RFID Temperature Logger Solar Rechargeable Tag is a new temperature logging tag that combines RFID technology with a solar-powered design, designed for long-term environmental monitoring and efficient data management. It supports EPC Class 1 Gen 2 V2, is compatible with ISO18000-6C, and operates at a frequency of 902–928 MHz, ensuring stable and reliable communication in diverse environments.
The RFID Temperature Logger Solar Rechargeable Tag uses a 3.7V DC power supply, significantly extending its service life and reducing battery replacement costs and maintenance. It operates in temperatures ranging from -30°C to +85°C, boasts a relative humidity tolerance of up to 95%, and features 4kV anti-static protection, making it suitable for use in a variety of extreme conditions.
Specification
| Dimension | 86mm x 54mm x 7mm |
| Weight | < 100g |
| Material | ABS |
| Color | Black (White is optional) |
| Installation | Location Inside Windshield |
| Protocol | EPC Class 1 Gen 2 V2(compatible with ISO18000-6C) |
| Frequency | 902-928MHz |
| Read Sensitivity | -18dBm in passive method / -26dBm in semi-active method |
Product application
Medical supplies: The Active RFID Tag Temperature Sensor provides reliable data logging, ensuring supplies are stored at the appropriate temperature and reducing risk.
Vehicle management: RFID readers and writers monitor the in-vehicle ambient temperature in real time, ensuring transparency and control over the transportation process.
Industrial monitoring: In temperature-sensitive production processes, this tag not only records temperature but also enables remote batch reading for precise monitoring and data tracking.
Products Advantages
Real-Time Temperature Monitoring: Continuously monitor temperature changes of electrical equipment and critical components to identify abnormal heat conditions before failures occur.
Long-Range RFID Wireless Reading: Supports RFID communication for remote data collection without direct physical contact, making inspection safer and more efficient in large power facilities.
Accurate Temperature Data Logging: Records temperature variations over time, providing reliable historical data for equipment analysis, maintenance planning, and operational safety.
Non-Invasive Installation on Electrical Equipment: Can be attached to transformers, switch cabinets, cables, and other power assets without changing existing equipment structures.
frequently ask question
Q: How does a solar rechargeable RFID temperature logger work when there is insufficient sunlight during transportation?
A: A solar rechargeable RFID temperature logger is designed with a low-power management system that combines photovoltaic charging and rechargeable battery storage. During normal operation, the solar panel converts ambient light energy into electrical power to maintain battery capacity.
When the tag is temporarily exposed to low-light environments, such as warehouses, containers, or transportation vehicles, the rechargeable battery provides backup energy to maintain temperature sensing and RFID communication functions.
Q: Why does the RFID temperature logger achieve a longer reading range than a UHF RFID tag?
A: The solar rechargeable RFID temperature logger uses a semi-active architecture. The integrated rechargeable power system provides additional energy support for sensor operation and signal communication, improving RF sensitivity.
Q: Can this RFID temperature logger record temperature data without a continuous connection to an RFID reader?
A: Yes. The RFID temperature logger is designed for distributed temperature monitoring scenarios where data collection is not always connected in real time.
The internal sensor records temperature information according to configured measurement requirements. When an RFID reader communicates with the tag, stored temperature information can be collected wirelessly. It reduces the need for manual inspection at each checkpoint.
Procurement & Partnership Information
Free consultation and sample support: We provide free consultation for corporate customers and system integrators, and you can apply for free samples to help you fully test and verify product performance before purchasing.
Quick proofing service: To meet the urgent needs of the project, we provide 2-3 days of fast proofing, support ODM/OEM/SKD mode, and help you quickly enter the verification and deployment stage.
Customized service: We can provide customized services such as barcode printing (monochrome/color), brand logo customization, personalized coding, etc. according to your project needs.
