Product Overview
Battery-free Passive RFID Temperature Sensors are thin, lightweight, and highly efficient UHF RFID tags designed for real-time temperature monitoring in industrial and supply chain environments. These passive RFID tags do not require batteries and can also achieve temperature sensing on metal surfaces.
Compliant with ISO18000-6C GEN2 protocol, with a read range of up to 5 meters and support for global frequencies of 860-960 MHz, Battery-free Passive RFID Temperature Sensors are ideal for OEM/ODM deployments in pharmaceutical logistics, logistics management, and warehouse temperature monitoring.
We provide fast sample delivery within 2-3 days, comprehensive encoding customization, and daily engineering support for integrators, suppliers, and project managers seeking scalable sensor-based RFID tag solutions.
Technical Specifications
| Tag Dimension | 95 × 30 × 0.2 mm |
| Antenna Size | 69 × 11 mm |
| Chip | CAB1 / VBL7 |
| Protocol | ISO18000-6C GEN2 |
| Memory | TID/UID: 112 bit EPC: 192 bit User File_0: 512 bit Reserve: 112 bit |
| Frequency Range | 860 – 960 MHz |
| Reading Range | Up to 500 cm (Air-Free, environment dependent) |
| Housing | White Printable PET |
| Installation Style | Hanging or Adhesive Application |
| Surface Compatibility | Anti-Metal Design |
| Customization | Mono/Color Barcode Text Printing Embossing / Laser Engraving EPC/UID Encoding |
| Sample Lead Time | 2–3 Days (OEM/ODM available) |
| Consulting Service | Free Solution Proposal & Engineering Evaluation |
ROI Benefits
Reduce Battery Maintenance Costs
Because the tag does not use a built-in battery, there is no regular battery replacement. For a deployment of 1,000 tags, even one battery replacement cycle requiring only 5 minutes per tag would represent more than 80 hours of maintenance labor. Battery-free operation removes this recurring task.
Save Installation Time on Metal Assets
The tag does not require wired power or a separate temperature probe. For large-scale deployments, a simple adhesive or hanging installation can reduce installation work from several minutes per monitoring point to less than one minute, depending on the application.
Lower the Cost of Large-Scale Monitoring
The thin passive design allows temperature sensing and RFID identification to be combined in one tag.
Reduce Manual Data Collection
UHF RFID enables multiple tags to be read wirelessly from a distance of up to 5 meters in suitable conditions. For warehouses with hundreds of monitoring points, this can reduce repetitive manual data collection time by 30–60%, depending on the reader setup and workflow.
FAQ
Q: Can it be installed on metal?
A: Yes. The tag uses an anti-metal design for applications involving metal surfaces.
Q: What is the maximum reading distance?
A: Up to 5 meters under suitable conditions. Actual performance depends on the reader, antenna, mounting surface, and environment.
Q: Can the tag be customized?
A: Yes. We support EPC/UID encoding, barcode and text printing, laser engraving, and OEM/ODM customization.
Q: How quickly can samples be prepared?
A: Standard samples can typically be prepared within 2–3 days, depending on the customization requirements.
